Drawn Cup Needle Roller Bearing

Product Description

You are welcomed to come to our factory to buy the latest selling, low price, and high-quality Drawn Cup Needle Roller Bearing, Top Bearings looks forward to cooperating with you.

Product Parameter

HK Drawn Cup:	Needle Roller Bearings With Open Ends	HK-RS HK-2RS:	Drawn Cup Needle Roller Bearings With Open Ends, Two Ends With Seal Ring
BK Drawn Cup:	Needle Roller Bearings With Closed End	BK-RS Drawn Cup:	Needle Roller Bearings With Closed End, One End With Seal Ring
F- Drawn Cup:	Needle Roller Bearings With Open Ends, Full Component	FY-Drawn Cup:	Needle Roller Bearings With Open Ends, Full Component Greased
MF- Drawn Cup:	Needle Roller Bearing With Closed End, Full Component	MFY- Drawn CupMFY- Drawn Cup:	Needle Roller Bearing With Closed End, Full Component, Greased
High Light:	single row roller bearing, radial needle bearing

MF MFY BK BK-RS HK HK-RS HK-2RS F FY Drawn Cup Of Needle Roller Bearings

Needle roller bearings have a high load carrying capacity in addition to their low cross-section and stiffness. They are especially suitable for bearing arrangements where radial space is limited. Because needle roller bearings only carry pure radial load and can not limit the axial displacement of shaft relative to the housing. It is important to ensure that inner ring axis and outer ring axis must be aligned during mounting the bearings.

Boundary dimensions(mm)			Basic load ratings(N)		Limiting speeds(rpm)	Mass(g)	Bearing Number
Fw	D	C	Cr	Cor	Oil	(Approx.)
4	8	8	1540	1070	40000	1.8	BK0408TN
5	9	9	2200	1790	36000	2.1	BK0509
45	52	16	19300	38000	5800	56	BK4516
45	52	20	22000	51000	5800	72	BK4520
50	58	20	28000	60000	5300	87.3	BK5020
50	58	25	34500	80000	5300	109	BK5025
55	63	20	29500	59900	4600	93.8	BK5520
55	63	28	39090	98000	4600	132	BK5528
60	68	12	12400	29000	4100	77	BK6012
60	68	20	30500	72000	4100	105	BK6020
60	68	32	50000	131000	4100	164	BK6032
6	10	8	1830	1550	32000	2.2	BK0608
6	10	9	2650	2400	3000	2.6	BK0609
7	11	9	2800	2150	27000	2.9	BK0709
8	12	8	2550	2400	21000	3	BK0808
8	12	10	3700	3450	21000	3.4	BK0810
8	14	10	3800	3950	25000	5.8	BK08X14X10
9	13	8	3650	4050	25000	3.4	BK0908
9	13	10	4050	4250	25000	4.3	BK0910
9	13	12	5000	6000	25000	4.9	BK0912

HK BK series
HK. RS HK. 2RS series
BK. RS series
NA RNA NK series
HF FC Series
HFL FCB series
K series KZK KBK series
AXK series AS GS 811 WS811
NATR NATV. PP series
NUTR. NUTR X series
IR IR series
NKIA NKIB series

HK Drawn cup needle roller bearings with open ends
HK-RS Drawn cup needle roller bearings with open ends, two ends with seal ring
HK-2RS Drawn cup needle roller bearings with open ends, two ends with seal ring
BK Drawn cup needle roller bearings with closed end
BK-RS Drawn cup needle roller bearings with closed end, one end with seal ring
F- Drawn cup needle roller bearings with open ends, full component
FY-Drawn cup needle roller bearings with open ends, full component greased
MF- Drawn cup needle roller bearing with closed end, full component
MFY- Drawn cup needle roller bearing with closed end, full component, greased

Drawn Cup Needle Roller Bearing MF MFY BK BK-RS HK HK-RS HK-2RS F FY 0
