Plugged Graphite Oscillating Spherical Plain Bearing

Supply Ability:

Plug Graphite Bearings, China, Manufacturers, Suppliers, Factory, Wholesale, Metal Journal Bearing, DU Self Lubricating Bearing, Composite Thrust Bearing, Composite Self Lubricating Bushings, Graphite Alloy Bearing, Flange Cast Iron Bearing

Application:

Excavators Bushings, Die/Mold Industry, Self-lubricating Bearing For Heavy Load Application

Lubrication:

Embedded Lubricant At Flange Allows To Bear Radial Journal Load And Thrust Load At The Same Time.

FEATURES:

Excellent Corrosion And Chemical Resistance.Maintenance-free,Excellent Wear Resistance,Low Friction,high Temperature Resistance

Bushing Application:

Parts Repair And Fabrication Services (Heavy Equipments, Automotive, Shipping Industry, Machinery, Etc)

High Light:

Spherical Plain Bearing SOBS

,

SOBS Metal Bush

,

Oscillating Spherical Plain Bearing

Technical information about the product

Bushes and plates

General technical information

Advantages of SANKYO Oilless bearings

Finishing

Sliding partner

Maintenance and lubrication

Transport and storage

Not what you are looking for?

Further materials

Custom-made products

Base Material:

Special Brass (SO#50SP2)

Self-lubricating:

Yes

Lubricant:

Graphite

Surface Pressure P:

100 N/mm²

Sliding speed v:

30 m/min

P*v-value:

200 N/mm² x m/min

Operating temperature:

-50°C / +200°C (max. 300°C)

Friction coefficient:

0,07

Article name

Inner diameter d

Outer diameter D

Width W

Angle a

S-øD1

l1

l2

Permitted radial load Rd (kN)

Permitted axial load Td (kN)

Rd x V permitted (kN x m/min)

Type

CAD-Download

Inquiry

SOBS 015

15

26

12

8°

22

9

4

6,5

0,5

6,5

A

SOBS 020

20

32

16

4°

28

14

4

12,6

1,4

12,6

A

SOBS 025

25

42

21

5°

36

18

4

21,8

2,5

21,8

A

SOBS 030

30

50

27

6°

44

23

4

32

3,5

32

A

SOBS 035

35

55

30

5°

49

26

4

43,7

4,8

43,7

A

SOBS 040

40

62

33

6°

55

28

4

54,7

5,7

54,7

A

SOBS 045

45

72

36

5°

62

31

4

69,7

7,2

69,7

A

SOBS 050

50

80

42

5°

70

36

4

92,4

10

92,4

A

SOBS 055

55

90

47

5°

80

40

4

117

13

117

A

SOBS 060

60

100

53

6°

90

45

4

143

16

143

A

SOBS 065

65

105

55

5°

94

47

4

162

18

162

A

SOBS 070

70

110

58

5°

99

50

4

181

20

181

A

SOBS 075

75

120

64

5°

105

55

4

217

25

217

A

SOBS 080

80

130

70

6°

115

60

4

254

30

254

A

SOBS 085

85

135

74

6°

120

63

4

283

33

283

A

SOBS 090

90

140

76

6°

125

65

4

313

36

313

A

SOBS 095

95

150

82

6°

135

70

4

428

50

428

A

SOBS 100

100

160

88

6°

145

75

6

544

64

544

B

SOBS 110

110

170

93

5°

155

80

6

642

73

642

B

SOBS 115

115

180

98

5°

165

85

6

719

83

719

B

SOBS 120

120

190

105

6°

170

90

6

797

94

797

B

SOBS 130

130

200

110

5°

180

95

6

880

105

880

B

SOBS 140

140

210

90

7°

180

70

6

668

56

668

B

SOBS 150

150

220

120

5°

200

105

6

1135

129

1135

B

SOBS 160

160

230

105

8°

200

80

6

891

73

891

B

SOBS 180

180

260

105

6°

225

80

6

1002

74

1002

B

SOBS 200

200

290

130

7°

250

100

6

1434

117

1434

B

SOBS 220

220

320

135

8°

275

100

9

1577

118

1577

B

SOBS 240

240

340

140

8°

300

100

9

1720

118

1720

B
