                                    Lead Free POM Boundary Lubricating Blue Thrust washer
                                    • Lead Free POM Boundary Lubricating Blue Thrust washerLead Free POM Boundary Lubricating Blue Thrust washer
                                    • Lead Free POM Boundary Lubricating Blue Thrust washerLead Free POM Boundary Lubricating Blue Thrust washer

                                    Lead Free POM Boundary Lubricating Blue Thrust washer

                                    As a professional high quality Lead Free POM Boundary Lubricating Blue Thrust washer manufacturers, you can rest assured to buy Lead Free POM Boundary Lubricating Blue Thrust washer and we will offer you the best after-sale service and timely delivery.

                                    Send Inquiry

                                    Product Description

                                    As a professional high quality Lead Free POM Boundary Lubricating Blue Thrust washer manufacturers, you can rest assured to buy Lead Free POM Boundary Lubricating Blue Thrust washer and we will offer you the best after-sale service and timely delivery.


                                    Product Parameter

                                    Material:

                                    Low-Carbon Steel + Porous Bronze + Blue POM

                                    Types:

                                    Wrapped Bushes, Thrust Washer

                                    Application:

                                    Vehicle Chassis, Forming Machine Tools, Steel Metallurgical Machinery, Mineral Mountain Machinery, Hydraulic Industry And Rolling Steel Industry, Etc.

                                    Heat-conducting Coefficient:

                                    52 W/(m*k)

                                    Heat-expansion Coefficient (Axial):

                                    11*10^-6k

                                    Working Temperature:

                                    -40~+120℃

                                    High Light:

                                    pom bearing, sleeve bearing bushing

                                    Lead - Free Boundary Self Lubricating DX Bushing , Blue POM Boundary Lubricating Bearings



                                    Among those professional lead-free boundary self-lubricating dx bushing TOB-2y manufacturers in China, welcome to buy customized and low price lead-free dx bushing, boundary self-lubricating bushing, marginal lubrication bearings, marginal lubricated bushing or get its free sample from our factory.



                                    Lead-free boundary self-lubricating DX bushing

                                    STRUCTURE: Metal-Polymer Composite Bushing Material
                                    COMPOSITION: Steel Back + Porous Bronze Sinter + POM with Lubrication Indents(without Pb)



                                    MICROSECTION:

                                    1. POM sliding layer with lubricant indents (without Lead)

                                    2. Porous Bronze Sinter

                                    3. Steel Backing

                                    4. Tin/Copper coating



                                    TECHNICAL DATA:

                                    Max.Load Static 140 N/mm2
                                    Dynamic 70 N/mm2
                                    Max line speed V(m/s) Grease lubrication 2.5 m/s
                                    PV value limit (N/mm2.m/s) 2.8 N/mm2.m/s
                                    Operating Temperature -60°C~+120°C
                                    Friction Coeff. 0.06~0.12
                                    Hardness (HB) > 270HB
                                    Roughness(Ra) 0.4~1.25
                                    Coeff. Of linear expansion 11x10-6/K



                                    CHARACTERISTICS:

                                    1. Lead-free boundary self-lubricating DX bushing TOB-2Y for grease or oil lubricated applications.

                                    2. Standard parts contain grease indents in the sliding layer, plain sliding layer available by request.

                                    3. Optimum performance under relatively high loads and low speeds.

                                    4. Suitable for linear, oscillating and rotating movements.

                                    5. Wide range of parts available from stock.



                                    TYPICAL APPLICATIONS: Lead-free boundary self-lubricating DX bushing TOB-2Y is widely used in Vehicle chassis, forming machine tools, steel metallurgical machinery, mineral mountain machinery, hydraulic industry and rolling steel industry etc.

                                    Lead - Free POM Boundary Lubricating Bearings DX Bushing , Blue Thrust washer 0



                                    Hot Tags: Lead Free POM Boundary Lubricating Blue Thrust washer, China, Manufacturers, Suppliers, Factory, Wholesale, Customized, In stock, Free Sample, Brand, Price
